Description
Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for
producing PET plastic containers and bottles in all shapes.
producing PET plastic containers and bottles in all shapes.
Working Principle
The left and right hydraulic cylinders are driven by the hydraulic system. making the tool rest swing in an arc around the support shaft to shear the plates. It is equipped with a nitrogen cylinder to achieve rapid return stroke.
Structural Features
The main body adopts an all-steel welded frame structure. which has high stability after vibration stress relief treatment. The blades usually adopt a multi-edge design: the upper blade has two cutting edges. and the lower blade has four cutting edges. The blades can be sharpened and turned over for use. extending their service life.
Performance Advantages
The blade gap can be flexibly adjusted through a stepless adjustment mechanism. with an indicator plate for guidance. enabling easy and quick adjustment. Some models are equipped with a closed-loop control system composed of an NC (Numerical Control) system and a position encoder. which can accurately ensure the precision of the back gauge displacement size. Meanwhile. they have various additional functions such as precision compensation and automatic detection.
Products Description
Safety Devices
It is equipped with a light alignment lighting device for accurate positioning of the shearing position. The working area is equipped with a fence-type personal safety protection device to prevent work-related accidents
Application Fields
It is mainly used in industries such as machinery manufacturing. automobile manufacturing. container
manufacturing. switchgear and electrical appliances. and light industry. It can be used for linear
manufacturing. switchgear and electrical appliances. and light industry. It can be used for linear
item | value |
Type | QC12K-4*2500 |
Cutting thickness (mm) | 4 |
Cutting length (mm) | 2500 |
Material / metal processed | Carbon Steel. STAINLESS STEEL. aluminum |
Weight (kg) | 3000 |
Dimension(mm) | 3040*1550*1550 |
Power(kw) | 4 |
Warranty | 1 years |
Core components | Bearing. Gearbox. PLC. GEAR. MOTOR |
Cutting angle (mm) | 1degree30minutes |
Throat depth (mm) | 150 |
Back-GaugeRange(mm) | 10-500 |
Travel times(cycle/min) | 12 |
Place of origin | China |
Brand name | Jetamc |
Automation | Semi-automatic |
Key selling points | High-accuracy |
