Description
Hydraulic guillotine shears are metal plate processing equipment that uses hydraulic transmission as power and adopts a guillotine-type shearing structure. Widely applied in fields such as metallurgy. shipbuilding. automobile manufacturing. and machinery manufacturing. they are mainly used for precise shearing of metal plates like carbon steel. stainless steel. and aluminum alloy. These shears can process plates into rectangular or special-shaped parts of different specifications. and are one of the core devices for primary processing of metal plates.
Core Structure
Hydraulic System: Composed of a hydraulic pump. hydraulic cylinder. relief valve. directional valve. etc.. it serves as the power source of the equipment. Shearing action is achieved through pressure transmission of hydraulic oil. featuring stable power and large output pressure.- Guillotine-type Tool Post: Adopting an integral rigid structure. the tool post is equipped with shearing blades. During shearing. the tool post moves vertically downward along the guide rail (similar to "gate closing"). ensuring uniform contact between the blade and the plate and reducing plate deformation.- Workbench and Back Gauge: The surface of the workbench is usually paved with wear-resistant pads to protect the plate surface from scratches. The position of the back gauge can be adjusted manually or via a numerical control system to accurately control the length of the sheared plate. making it a key component for ensuring shearing precision.- Safety Protection Devices: Equipped with infrared photoelectric protection. guardrails. emergency stop buttons. etc. When a human body or foreign object enters the shearing area. the equipment will stop running immediately to avoid safety accidents.
Working Principle1.According to processing requirements. the operator sets parameters such as the thickness and length of the plate to be sheared through the control panel (for numerical control equipment. programs can be directly input).2. After starting the equipment. the hydraulic pump operates. pressurizes the hydraulic oil. and delivers it to the hydraulic cylinder.3. The hydraulic cylinder pushes the guillotine-type tool post to move downward along the guide rail. The blade comes into contact with the plate on the workbench surface. and the shearing is completed by overcoming the shear strength of the plate through hydraulic pressure.4. After shearing. the hydraulic system reverses direction. and the tool post resets under the action of a return device (such as a spring or hydraulic cylinder). The operator takes out the sheared plate and enters the next processing cycle
Products Description
Main Features and Advantages1. High Shearing Precision: The guillotine-type shearing structure ensures uniform force on the blade. Combined with the precise positioning of the numerical control back gauge (the positioning accuracy of some models can reach ±0.1mm). it can effectively ensure the dimensional consistency of plates processed in batches and reduce plate warping and deformation.2. Strong Shearing Capacity: The hydraulic transmission system can provide large shearing force (the shearing force range of common models is 500kN-6000kN). It can shear metal plates with a thickness of 8mm-60mm and a width of 1.6m-6m. meeting the processing needs of medium and thick plates.3. Easy Operation: Manual-type equipment adjusts parameters through handles. which is simple and easy to learn. Numerical control equipment is equipped with a touch screen and PLC control system. supporting parameter storage and program calling. It can realize automated batch processing and reduce the intensity of manual operation.4. Stable and Reliable Operation: The hydraulic system adopts a mature circuit design. Combined with the rigid tool post and high-quality guide rail. the equipment has low vibration and low noise (usually ≤85dB) during operation. In addition. vulnerable parts (such as blades and seals) are easy to replace. resulting in low maintenance costs.5. Wide Adaptability: By replacing blades of different materials (such as high-speed steel blades and alloy blades). it can adapt to metal plates of different hardness. including carbon steel. stainless steel. and aluminum alloy. to meet diverse processing needs. Some models can also be equipped with pneumatic brackets and feeding mechanisms to improve the convenience of processing long and heavy plates.
item | value |
Type | QC11K-12*4000 |
Cutting thickness (mm) | 12 |
Cutting length (mm) | 4000 |
Material / metal processed | Carbon Steel. STAINLESS STEEL. aluminum |
Weight (kg) | 13000 |
Dimension(mm) | 4430*2655*2570 |
Power(kw) | 18.5 |
Warranty | 1 years |
Core components | Bearing. Gearbox. PLC. GEAR. MOTOR |
Cutting angle (mm) | 0.5-5.5degree |
Throat depth (mm) | 150 |
Back-GaugeRange(mm) | 10-500 |
Travel times(cycle/min) | 8 |
Place of origin | China |
Brand name | Jetamc |
Automation | Semi-automatic |
Key selling points | High-accuracy |
